CUT & BENT

Form Direct holds the following sizes as standard stock items.

LIGATURES HOOPS
with overlap with overlap

Represents
overlap

Represents
overlap

Code Dimension Code Dimension
LR62025 R6 200 x 250mm R10H200 200mm
LR62035 R6 200 x 350mm R10H300 300mm
LR102025 R10 200 x 250mm R10H400 400mm
LR 102035 R10 200 x 350mm R10H500 500mm

CORNER BARS STARTER BARS
Bent at 90°

90 o
45 o

90 o

Code Dimension
Code Dimension SB12102 200 x 1000mm
CB1255 500 x 500mm @ 90 o SB12122 200 x 1200mm
CB125545 500 x 500mm @ 45 o SB12091 100 x 900mm
CB1266 600 x 600mm @ 90 o SB12111 100 x1100mm
CB126645 600 x 600mm @ 45 o SB12096 600 x 900mm

RE-ENTRANT BARS FOR ALL YOUR CUT & BENT
Straight
STEEL REQUIREMENTS

Code Dimension PHONE US TODAY!
N12C10 1000mm
N12C12 1200mm 1300 659 830
N12C20 2000mm
