TRENCH MESH SUPPORT

Plastic Trench Mesh Supports
are used to locate and support
Trench Mesh. Suitable for all
Trench Mesh sizes, plastic BTMS
trench mesh supports are TMS65
ideal for footing beams and
waffle pod slab perimeters. Code Description Bag Qty Code Description Bag Qty
TMS65 65mm Suit Bar 8 to 12 20 BTMS 65mm Suit Bar 8 to 16mm 20

TOP DECK SPACER BOTTOM DECK SPACER H/DUTY PLASTIC SPACER

Top Deck Spacers are used The bottom deck spacer supports both
to set concrete cover within mesh and large bars in suspended H/Duty Plastic Spacer
suspended slabs, tilt-up decks, pre-cast beams and panels, and are designed for large
and pre-cast panels. tilt-up applications. As an alternative to bar diameters in heavy
Available in dual heights wire chairs, the bottom duty applications.
with a clip on mechanism deck spacers are Supplied with a central
for stability. Available in lighter, offer dual hole for tie wire. Available
heights from 20 up to 200 mm. heights and have in heights ranging from 25 to 70 mm.

Code Description Bag Qty no rust problems. Code Description Bag Qty
6575 65 or 70mm 100 NB-20/35 20-30mm 100
90100 90 or 100mm 100 NB-40/55 45-50mm 100
110120 110 or 120mm 100 Code Description Bag Qty NB-60/75 60-75mm 50 FORMWORK & REINFORCING
130140 130 or 140mm 100 2530 25 or 30mm 100
150160 150 or 160mm 100 3040 30 or 40mm 100 HEAVY DUTY CONCRETE
170180 170 or 180mm 100 3545 35 or 45mm 100 SPACER
190200 190 or 200mm 100 4050 45 or 50mm 100
Combination spacers are suitable
for horizontal reinforcement and
MESH SPACER CLIP-ON CONCRETE ASPRO where structural elements are
subject to extreme temperature
Mesh Spacer Clip-ons Concrete Aspros with Tie Wire variations.
are used to set are used in a range of civil and Available in bags of
the reinforcing bar infrastructure projects. 125 or 250, heights
and mesh to the Compliant with Roads range from
correct position Authority requirements, 35 x 40 x 50 mm
within the concrete cover. concrete aspros are heat 45 x 55 x 60 mm
Ideal for use in polystyrene tolerant and stable for 50 x 60 x 70 mm
pod slabs, slab-on-ground concrete cover.
and swimming pools. Available in various Code Description Bag Qty
block heights. NAO3572 35/40/50 250
Code Description Bag Qty Code Description Bag Qty NAO4573 45/55/60 125
25M 25mm 100 ASPRO50 50mm 60 NAO7513 75mm 125
32M 32mm 100 ASPRO65 65mm 40 NAO8513 85mm 100
40M 40mm 100 ASPRO75 75mm 30 NAO10013 100 x 28mm 75
50M 50mm 100 ASPRO65H 65 x 65mm Wire 40 NAO100X40 100 x 40mm 60
65M 150 or 160mm 100 ASPRO75H 75 x 75mm Wire 30 NAO85X28 85 x 28mm 100
75M 170 or 180mm 100 CBF6550 50 x 65 x 75mm 25 NAO85X40 85 x 40mm 40
