DOWEL SLEEVES
SPEED SLEEVE DRY DOWEL SERT ROUND DOWEL
More sizes
Speed Sleeves are used available cut to
with round dowels to • Bag 25 any length
eliminate the need for
drilling formwork and
greasing Dowels.
Round Dowel
Black & Galvanised
Code Description Code Description
SPDSLV16X240 16mm x 240mm Code Description R12 12mm Black per L/M
SPDSLV16X310 16mm x 310mm DS16450NS 16mm suits 450mm Dowel R12G 12mm Galvanised per L/M
SPDSLV20X240 20mm x 240mm DS16600NS 16mm suits 600mm Dowel R16 16mm Black per L/M
SPDSLV20X310 20mm x 310mm DS20450NS 20mm suits 450mm Dowel R16G 16mm Galvanised per L/M
SPDSLVNAIL16 16mm Nail Plate DS20600NS 20mm suits 600mm Dowel R20 20mm Black per L/M
SPDSLVNAIL20 20mm Nail Plate DS24.600S 24mm suits 600mm Dowel R20G 20mm Galvanised Per L/M
DOWELMASTER DOWEL CAP SQUARE DOWEL
Plastic Round Dowel
Caps fit over the dowel
and allow longitudinal FORMWORK & REINFORCING
movement. Suitable Square Dowel
for 16 mm up to 24 Black & Galv
Code Description mm diameter dowels.
SQDWMAST16MM 16mm with Stake Available in bags of 100. Code Description
SQDWMAST20MM 20mm with Stake SQDWL16X400B 16mm x 400mm Black
SQDWMASTNL16 16mm Nail Plate Code Description Bag Qty SQDWL20X400B 20mm x 400mm Black
SQDWMASTNL20 20mm Nail Plate DCP B 12-24mm 100 SQDWL20X400G 20mm x 400mm Galv
FLANGED BOX METAL COVERS LOOKING FOR
POST SUPPORTS,
STARTER BARS
OR THREADED
A galvanised steel cover with foam ROD?
strips each side, sized to suit
Flange Dowel Boxes are well suited anticipated dowel movement both Refer to page 112
for use in construction joints in both perpendicular and parallel to the joint.
ground slabs and elevated slabs. Metal covers are available in 16, 20,
Flanged Boxes are available to suit 25 & 32.
square dowel in 16, 20, 25, 32 & 40.
Code Description
Code Description DWLSQCV20X250 20 x 250mm
DWLFLBOX32X220 32 x 220mm DWLSQCV32X200 32 x 200mm
