WATERSTOPS

HYDROTITE WATERSTOP PENEBAR SW WATERSTOP

Premium grade, water Hydrophilic Waterstop
swellable, waterstop range (Rapid or Controlled
for use in cast in-situ Expansion) used for the
concrete. Upon expansion sealing of typical
Hydrotite turns from a construction joints
dark blue colour to a light (horizontal and vertical)
blue colour so that a visual and pipe penetrations.
inspection of the Hydrotite Before After
can be made and the Expansion Expansion
contractor can check if the
Hydrotite has pre-expanded.

Code Description Code Description
2200560 Hydrotite DSS0220 PF AD Waterstop 25mtr 214530 Penebar Sw45 Rapid 19x25mm 5m/Coil

LEAKMASTER

Gun applied, water-swellable, waterstop paste
Leakmaster is used for bonding Hydrotite profiles to
rough concrete surfaces, water sealing joints of cast
in-situ concrete, water sealing around "H" section steel
joists, sealing rough surfaces, shotcrete and box culverts.
Code Description
2200785 Leakmaster 320ml Cartridge

SUPERCAST

This range of PVC waterstops is designed to provide an
integral sealing system for movement and construction
joints in concrete cast in-situ. These joints typically occur
in the following types of structure:
Water retaining
• Reservoirs, water towers and sewage tanks
• Dams, culverts, canals and spillways
• Swimming pools
• Bunded areas surrounding liquid retaining tanks
Water excluding
• Basements and underground car parks Water Stop Backing Rod Polyurethane Sealant
• Tunnels and subways
• Abutments and retaining walls
• Roof decks and podium areas

Concrete Slab WWR
