DRAINAGE

THE SURFACE WATER DRAINAGE SYSTEM

A complete system

The Reln Surface Water Drainage System is a complete solution for
the collection and dispersal of surface water. Typical applications
include around patios, swimming pools, sports courts, and gardens,
across driveways, along pathways and retaining walls, in fact any
area where surface water collects.

Easy to install
Comes with user-friendly installation instructions.

7
9

5

4 6 90° Corner allows 4 Leaf Leaf Guard
prevents
left or right hand
leaves from
extension of the
outlets and
Reln Storm Drain. Guard blocking
pipes.
3 3m Channel
Easy clip out grate
for cleaning
1 2 Joiner
Pre drilled End Outlet
is quicker to install
Easy 6 90° Corner PVC stormwater pipe.
1 Slim-line Pit joining
5 End Outlet

8 Tee Piece
Preformed pipe 7 End Cap
outlets allow for
quick and easy
glueing of 9 1m Channel Bottom outlet can be cut
ø90mm PVC or drilled to allow more
stormwater pipe ø90mm PVC flexibility with paving.
Stormwater Pipe

3

90 Degree Civil Corner 3m Channel Civil Slim-line Pit
